ch7210

如果您对产品有相关疑问,或者遇到任何,您都可以注册网站帐号,
然后到利来app官网的技术支持论坛去提问寻求帮助。

特征

  1. compliant with displayport alternate mode on usb type c standard
  2. compliant with displayport specification version 1.3 and embedded displayport (edp) specification version  1.4
  3. support 2 main link lanes at 1.62gbps,2.7gbps (hbr) or 5.4gbps (hbr2) link rate
  4. automotive dp input signal detection and lane swap supported for compliance with the usb type c cable plug orientation switch
  5. dp_br signaling modes supported
  6. displayport receiver auto equalization supported for the compensation of input signal attenuation
  7. support spread spectrum clocking (de-spreading) for emi reduction
  8. fast and full link training for embedded displayport system
  9. support edp authentication: alternative scramble seed reset and alternative framing
  10. usb power delivery control module supported with hpd to pd converter integrated
  11. hdmi transmitter compliant with hdmi specification version 2.0 and dvi specification version 1.0
  12. hdmi transmitter supports up to 3.0gbps data rate for video timing of 4kx2k@30hz, or 4k2k@60hz on ycc 4:2:0 mode
  13. hdmi 3d dual view and 3d audio are supported
  14. high-dynamic-range (hdr) display are supported
  15. ycc 4:4:4/4:2:2 to ycc 4:2:2/4:2:0,y-only(gray display) conversion are supported
  16. hdcp engine compliant with hdcp 2.2 specification with internal hdcp keys
  17. hdcp 2.2 repeater supported
  18. active ddc buffer and related control register integrated
  19. iic-over-aux transaction supported
  20. programmable equalizer
  21. programmable pre-emphasis on output driver supported
  22. on-chip audio decoder which support 8 channel audio input from dp rx and output from hdmi tx with sample rate up to 192khz
  23. support 2 usb type-c ports that are compliant with usb type-c cable and connector specification revision 1.3.
  24. compliant with usb power delivery specification revision 3.0, version 1.1, with usb power delivery bmc transceiver integrated on each usb type-c port
  25. integrated ra, rd and rp for usb type-c
  26. embedded mcu to handle the control logic
  27. usb billboard module integrated
  28. usb 2.0 phy supported
  29. embedded eeprom, integrated edid buffer
  30. iic slave and usb 2.0 port are available for firmware update.
  31. support auto power saving mode and low stand-by current
  32. anti-back drive support
  33. low power architecture
  34. rohs compliant and halogen free package
  35. hbm 2kv esd performance
  36. offered in 48 pin qfn package (7 x 7 mm)

描述

chrontel’s ch7210 is a low-cost, low-power semiconductor device that translates the displayport to hdmi 1.4 converter on usb type c. this innovative usb type-c based displayport receiver with an integrated hdmi transmitter is specially designed to target the usb type-c to hdmi converter, adopter and docking device. through the ch7210’s advanced decoding / encoding algorithm, the input displayport high-speed serialized multimedia data can be seamlessly converted to hdmi/dvi output.the ch7210’s dp/edp receiver is compliant with the displayport specification 1.3 and embedded displayport (edp) specification version 1.4. with sophisticated displayport signal detection and the lane swap/aux polarity inversion logic, the ch7210 supports usb type- c cable plug orientation switch. with internal hdcp key integrated, the device support hdcp 2.2 specifications. in the device’s receiver block, which supports four displayport main link lanes input with data rate running at 1.62gbps, 2.7gbps or 5.4gbps, and converted the input signal to hdmi output up to 4kx2k@30hz. leveraging the usb power delivery control logic, the usb billboard module for usb device indentify and displayport’s unique source/sink “link training” routine, the ch7210 is capable of instantly bring up the video display to the hdmi/dvi tv/monitor when the initialization process is completed.the ch7210 also supports up to 8-channel audio input from either dp rx and output from hdmi tx with sample rate up to 192 khz. available audio bandwidth depends on the pixel clock frequency, the video format timing, and whether or not content protection re-synchronization is needed.with sophisticated mcu and the on chip flash, ch7210 support auto-boot and edid buffer. leveraging the firmware auto-loaded from flash, ch7210 can support dp input detection, hdmi connection detection, and determine to enter into power saving mode automatically.


结构图

数据表

应用说明

暂无信息

技术报告

暂无信息

规格

暂无信息

订单信息

暂无信息

视频

暂无信息
