特征

        compliant with displayport alternate mode on usb type c standard
  compliant with displayport specification version 1.3 and embedded displayport (edp) specification version 1.4
  support up to 4 main link lanes at 1.62gbps,2.7gbps (hbr) or 5.4gbps (hbr2) link rate
  automotive dp input signal detection and lane swap supported for compliance with the usb type c cable plug orientation switch
  dp_br signaling modes supported
  programmable displayport receiver equalization supported for the compensation of input signal attenuation
  support spread spectrum clocking (de-spreading) for emi reduction
  support fast and full link training
  support edp authentication: alternative scramble seed reset and alternative framing
  hdmi transmitter compliant with hdmi specification version 2.0 and dvi specification version 1.0
  hdmi transmitter supports up to 6.0gbps data rate for video timing of 4kx2k@60hz
  hdmi 3d dual view and 3d audio are supported
  high-dynamic-range (hdr) display are supported
  ycc 4:4:4/4:2:2 to ycc 4:2:2/4:2:0,y-only(gray display) conversion are supported
  hdcp engine compliant with hdcp 2.2 specification with internal hdcp keys
  hdcp 2.2 repeater supported
  active ddc buffer and related control register integrated
  scdc supported on hdmi ddc
  iic-over-aux transaction supported
  cec tunneling over aux is supported
  aux ch polarity inversion supported for usb type c cable plug orientation switch
  programmable pre-emphasis on output driver supported
  support 2 usb type-c ports that are compliant with usb type-c cable and connector specification revision 1.3.
  compliant with usb power delivery specification revision 3.0, version 1.1, with usb power delivery bmc transceiver integrated on each usb type-c port
  integrated ra, rd and rp for usb type-c
  on-chip audio decoder which support 8 channel audio input from dp rx and output from hdmi tx with sample rate up to 192khz
  spdif/iis input supported with audio sampling rate up to 192khz
  embedded mcu to handle the control logic
  full speed usb billboard module integrated
  usb 2.0 phy supported with internal switch for
data/file transport

  • embedded eeprom, integrated edid buffer
  • iic slave, usb 2.0 are available for firmware update
  • iic slave interface are available for debug
  • support auto power saving mode and low stand-by current
  • anti-back drive support
  • low power architecture
  • rohs compliant and halogen free package
  • hbm 2kv esd performance
  • offered in 64 pin qfn package



描述

chrontel’s ch7211 is a low-cost, low-power semiconductor device that translates the displayport signal to hdmi/dvi through the usb type-c connector. this innovative usb type-c based displayport receiver with an integrated hdmi transmitter is specially designed to target the usb type-c to hdmi converter, adopter and docking device. through the ch7211’s advanced decoding / encoding algorithm, the input displayport high-speed serialized multimedia data can be seamlessly converted to hdmi/dvi output.

the ch7211’s dp/edp receiver is compliant with the displayport specification 1.3 and embedded displayport (edp) specification version 1.4. with sophisticated displayport signal detection and the lane swap/aux polarity inversion logic, the ch7211 supports usb type-c cable plug orientation switch. with internal hdcp key integrated, the device support hdcp 2.2 specifications. in the device’s receiver block, which supports four displayport main link lanes input with data rate running at 1.62gbps, 2.7gbps or 5.4gbps, and converted the input signal to hdmi output up to 4kx2k@60hz. leveraging the usb power delivery control logic, the usb billboard module for usb device indentify and displayport’s unique source/sink “link training” routine, the ch7211 is capable of instantly bring up the video display to the hdmi/dvi tv/monitor when the initialization process is completed.

the ch7211 also supports up to 8-channel audio input from either dp rx or spdif port and output from hdmi tx with sample rate up to 192 khz. available audio bandwidth depends on the pixel clock frequency, the video format timing, and whether or not content protection re-synchronization is needed.

with sophisticated mcu and the on chip flash, ch7211 support auto-boot and edid buffer. leveraging the firmware auto-loaded from flash, ch7211 can support dp input detection, hdmi connection detection, and determine to enter into power saving mode automatically.

结构图

数据表

应用说明

 ·         usb type c to hdmi cable/adapter/docking station

·         handheld/portable device

技术报告

暂无信息

规格

暂无信息

订单信息

暂无信息
