ch7033

如果您对产品有相关疑问,或者遇到任何,您都可以注册网站帐号,
然后到利来app官网的技术支持论坛去提问寻求帮助。

特征


  • dvi encoder support up to 1080p

  • supports component yprpb (hdtv) up to 1080p and analog rgb (vga) monitor up to 1920x1080 resolution

  • support scaled and bypassed video streams output from vga/hdtv and dvi interfaces simultaneously

  • three 10-bit high speed dacs

  • spdif audio interface supports either 16-bit or 20-bit stereo data for up to 192khz/2ch

  • support 2 channel i2s digital audio input for up to 24-bit data stream (32khz, 44.1khz, 48khz, 88.2khz, 96khz, 176.4khz and 192khz)

  • ddc master for reading edid

  • hot plug detection for dvi

  • tv/monitor connection detect capability. dacs can be switched off through programming internal registers

  • pixel-level color enhancement for brightness, contrast, hue and saturation adjustment for hdtv and vga output

  • on-chip frame buffer supports frame rate conversion provides the graphic controller the flexibility of video timing output

  • advanced scaling engine to upsize/downsize input resolution for dvi display up to 1080p, vga up to 1920 x1080 and hdtv up to 1080p

  • supports 8/12/16/18/24-bit parallel interface input for either rgb format (rgb-565, rgb-666 or rgb-888 and etc.) or ycrcb format (itu-r 656 or itu-r 601). 80/86 mpu interface and de only mode are also supported.

  • wide range of input resolutions support for up to 1366x768 (i.e. 640x480, 720x480, 720x576, 800x600, 1024x600, 1024x768, 1280x800, and etc.)

  • image display rotation support at 90/180/270 degree or flipped in horizontal/vertical position

  • pixel clock input frequency support for up to 165 mhz

  • io supply voltages from 1.2v to 3.3v and spc/spd supply voltages from 1.8v to 3.3v.

  • programmable power management

  • device fully programmable through serial port or can automatically load firmware from chrontel boot rom (ch9904)

  • offered in a package

描述

the chrontel ch7033b is specifically designed for consumer electronics device and pc markets which multiple high definition content display formats are required. with its advanced video encoder, flexible scaling engine and easy-to-configure audio interface, the ch7033b satisfies manufactures’ products display requirements and reduce their costs of development and time-to-market. high quality high-bandwidth uncompressed video like dvi and yprpb components or legacy vga analog display are supported by the device’s color format converter. the 3 high-performance, 10-bit dacs can be used for either hdtv display or vga output depending on manufactures’ products specification. the device is compliant with eia770-3 and smpte 274m/293m/296m standards and supports hdtv resolution for up to 1080p. the ch7033b has the ability to generate composite syncs if required by the rgb monitor. the ch7033b’s 24-bit parallel bus accepts a wide range of input data formats from the graphic controller. the built-in video port supports 8/12/16/18/24-bit data interface as well as 80/86 mpu interface. the video format conversion module is capable of translating digital rgb-565, rgb-666, rgb-888 or ycrcb (itu-r 656, itu-r 601) signal to the dvi signal, combining with the audio stream. the input digital signal also can be transformed by the dacs for hdtv or vga analog outputs. the device’s video capture block supports input display resolution for up to 1366x768 which can be either interlaced or non-interlaced timing. the ch7033b has incorporated a high speed sdram that allows manufactures to design their products to achieve simultaneous display digital signal and analog signal. leverage the benefit of the framebuffer, the device’s sophisticated scaler is able to produce two same video content, which will be routed to separate output driver for display. frame rate conversion is embedded in the scaler; it can maximize the native input resolution up to 1080p for hd display. furthermore the ch7033b provides additional image manipulation features including image rotation that can be controlled through programming internal registers. the device supports both spdif and 2-channel i²s digital audio input. its high fidelity audio decoder engine has the capability of sampling audio frequency for up to 192k/2ch. the spidf supports pcm encoded data and compressed audio including dolby digital and dts. the ch7033b has an image enhancement function that can fine tune brightness, contrast, hue and saturation down to the pixel-level. when the hpd signal is asserted, the ch7033b will automatically generate an interrupt to the processor. a build-in ddc port can read the edid data from dvi monitor through programming registers by the processor.

结构图

数据表

应用说明

 pcb layout and design guide for ch7033b and ch7051b, an-b012 rev1.7

 ch7033b/7051b user guide, an-b017 rev1.9

 refer to the an-b037 for industrial products in detail

技术报告

暂无信息

规格

input interface  ttl/digital rgb, ttl/ycbcr, ttl/bt1120

output interface   hdmi, dvi, vga, ypbpr

audio interface  iis, spdif input

other features  scaler, frame buffer

package type  qfn88

订单信息

暂无信息

视频

part number  package type number of pins operating temperature range

ch7033b-bf  lead free - qfn88commercial : -20 to 70°c

ch7033b-bfi  lead free - qfn88industrial : -40 to 85°c
