ch7301c

如果您对产品有相关疑问,或者遇到任何,您都可以注册网站帐号,
然后到利来app官网的技术支持论坛去提问寻求帮助。

特征

  • dvi transmitter up to 165m pixels/second

  • dvi low jitter pll

  • dvi hot plug detection

  • supporting graphics resolutions up to 1600 x 1200 pixels and 1920x1200 reduced blanking

  • provides rgb output

  • dac connection detection

  • programmable power management

  • fully programmable through serial port

  • complete windows and dos driver support

  • low voltage interface support to graphics device

  • three 10-bit video dac outputs

  • offered in a package

描述

the ch7301c is a display controller device which accepts a digital graphics input signal, and encodes and transmits data through a dvi or dfp (digital flat panel). the device accepts data over one 12-bit wide variable voltage data port which supports different data formats including rgb and ycrcb.

the dvi processor includes a low jitter pll for generation of the high frequency serialized clock, and all circuitry required to encode, serialize and transmit data. the ch7301c comes in versions able to drive a dfp display at a pixel rate of up to 165mhz, supporting uxga resolution displays. no scaling of input data is performed on the data output to the dvi device. see figure 1 for the functional block diagram of the ch7301c.

color space conversion from ycrcb to rgb is supported in both dvi and vga bypass modes.

结构图

数据表

应用说明


  •   ch7301 registers read/write operation, an-41.pdf.

  •   a pcb design guideline to prevent dvi signaling power-reverting in ch7301, an-57.pdf.

  •   pcb layout and design considerations for ch7301c dvi output device, an-68.pdf.

  •   dacs connection detection of ch7301 encoders, an-71.pdf.

技术报告


  •   dvi output eye diagrams of ch7301a vs. ch7301b, tb-41.pdf.

  •   pcb design considerations of dac outputs with multiple video formats, tb-45.pdf.

规格

input interface  dvo , ttl/digital rgb, ttl/ycbcr

output interface  dvi, vga

audio interface   no

other features   no

package type  lqfp64
