ch7035

如果您对产品有相关疑问,或者遇到任何,您都可以注册网站帐号,
然后到利来app官网的技术支持论坛去提问寻求帮助。

特征


  • single / dual lvds transmitter

  • supports pixel rate up to 165m pixels/sec

  • supports up to uxga resolution (1600 x 1200)

  • lvds low jitter pll

  • lvds 24-bit or 18-bit output

  • 2d dither engine for 18-bit output

  • panel protection and power down sequencing

  • programmable power management

  • fully programmable through serial port

  • complete windows and dos driver support

  • variable voltage interface to graphics device

  • offered in a package

描述

the ch7305a is a display controller device, which accepts a graphics data stream over one 12-bit wide variable voltage (1.1v to 3.3v) port. the data stream outputs through an lvds transmitter to an lcd panel. a maximum of 165m pixels per second can be output through a single or dual lvds link.

the lvds transmitter supports 24-bit panels; it also includes a programmable dither function for support of 18-bit panels. data is encoded into commonly used formats, including those detailed in the openldi and the spwg specification. serialized data output on four or eight differential channels.

结构图

数据表

应用说明

  •   pcb layout and design considerations for ch7035 single lvds transmitter, an-b008.pdf (2/12/03)

技术报告

lvds dithering, tb-44.pdf (8/13/03)

规格

input interface dvo , ttl/digital rgb, ttl/ycbcr

output interface lvds

audio interface  no

other features   no

package type  lqfp64

订单信息

暂无信息

视频

暂无信息
