ch7307c

如果您对产品有相关疑问,或者遇到任何,您都可以注册网站帐号,
然后到利来app官网的技术支持论坛去提问寻求帮助。

特征


  • digital visual interface (dvi) transmitter up to 165m pixels/second

  • dvi low jitter pll

  • dvi hot plug detection

  • supporting graphics resolutions up to 1600x1200 pixels and 1920x1200 (reduced blanking)

  • high-speed sdvo*(1g~2gbps) ac-coupled serial differential rgb inputs

  • programmable power management

  • fully programmable through serial port

  • configuration through intel® opcodes*

  • complete windows and dos driver support

  • offered in a 48-pin lqfp package

  • boundary scan support





  •
  •
  •
  •



*intel® proprietary.

描述

the ch7307c is a display controller device, which accepts digital graphics input signal, encodes and transmits data through a dvi link (dfp can also be supported). the device accepts one channel of rgb data over three pairs of serial data ports.

the dvi processor includes a low jitter pll for generation of the high frequency serialized clock, and all circuitry required encoding, serializing and transmitting the data. the ch7307c is able to drive a dfp display at a pixel rate of up to 165mhz.

结构图

数据表

应用说明

  pcb layout and design considerations for ch7307c sdvo dvi transmitter, an-74.pdf (1/27/05)

技术报告

暂无信息

规格

input interface  sdvo

output interface  dvi

audio interface  no

other features  no

package type  lqfp48

订单信息

part number package type number of pins voltage supply temperature grade

ch7307c-def  lead free lqfp with exposed pad482.5v & 3.3vcommercial / automotive grade 4

ch7307c-def-tr lead free  in tape & reel482.5v & 3.3vcommercial / automotive grade 4
