ch7515a-利来app官网

ch7515a-tf

如果您对产品有相关疑问,或者遇到任何,您都可以注册网站帐号,
然后到利来app官网的技术支持论坛去提问寻求帮助。

特征


  • supports embedded displayport (edp) specification version 1.2.

  • support 4 main link lanes at either 1.62gb/s or 2.7gb/s link rate

  • supports input color depth 6/8/10-bit per pixel in rgb format

  • support vesa and cea timing standards up to qsxga 2560x2048 @ 60hz or wqxga 2560 x 1600 @ 60hz for 2d, and full hd 1920x1080 @120hz for 3d(l/r eye frame at 60hz each), with 10 bit graphic color depth

  • support edp authentication: alternative scramble seed reset (assr) and alternative framing

  • support single port, dual port and quad port lvds output interface with 6/8/10-bit color depth up to 400mhz pixel rate

  • support both openldi (or jeida), spwg (or vesa) and non-jeita (10-bit only) bit mapping for lvds application

  • flexible lvds output pins swapping

  • 2 channel iis/ s/pdif audio output

  • support dynamic backlight luminance control by the command through aux channel, or through the interface of pwm in/out and backlight brightness control (osd display)

  • support pwm bypass through and on-chip pwm generation (range 30~100%)black panel during invalid input

  • support panel selection function with external hardware configuration

  • initiated and controlled by firmware which is loaded from external boot rom automatically upon power up.

  • boot rom data updated through i2c bus or aux channel

  • support dynamic refresh rate (ddr) switching

  • supports enhanced framing mode

  • 3 work modes: connect 27mhz crystal, inject 27mhz or 14.318mhz clock

  • programmable lcd panel power sequence

  • hot plug detection

  • support chip power down by gpio pin

  • support power management mechanism through aux channel

  • emi reduction capability for dp input and lvds output. spread spectrum control is available for transmitting lvds signal

  • achieve bit error rate <10-9 for raw transport data per lane and symbol error rate <10-12 for control data

  • low power consumption

  • offered in a 128-pin tqfp package (14 x 14mm)

描述

chrontel's ch7515 is a low-cost, low-power semiconductor device that translates the embedded displayport signal to the lvds in form of rgb/ycbcr 4:4:4/ycbcr 4:2:2. this innovative edp receiver with integrated 4 channel lvds transmitters is specially designed to target the all-in-one pc and the notebook market segments. leveraging the displayport's unique source/sink "link training" routine, the ch7515 is capable of instantly bring up the video display to the lcd when the initialization process is completed between ch7515 and the graphic chip. the ch7515 is designed to meet the embedded displayport specification version 1.2. the 4 edp main link lanes receiver supports input with data rate running at either 1.62gb/s or 2.7gb/s, and can accept digital rgb signal for lvds output up to qsxga 2560x2048@60hz. with advanced 3d processing module integrated, the ch7515 can support up to 1920x1080@120hz 3d display mode, with programmable emitter control signal and 3d lcd panel's backlight control signal output. the backlight enable control and the pwm are the two kinds of backlight control functions designed in the ch7515 panel power control module. the brightness control commands sent through aux channel can be dynamically translated by ch7515 and converted into lcd backlight control signal. alternatively, the brightness control commands can be input from the pwm in and goio pin of backlight brightness control. the ch7515 will save the last setting of brightness level into the external boot rom and restore it upon power up. the ch7515 can dynamically adjust backlight brightness according to video stream to save power consumption and it supports osd display in this way. the ch7515 will immediately convert the embedded displayport signal to lvds output after displayport link training is completed. this feature can be achieved by loading the panel's edid and the ch7515's configuration settings in the serial external boot rom connected to the ch7515. during system power-up and upon completion of the displayport link training through aux channel, ch7515 will generate lvds signal according to the panel power-up timing sequencing stored in the external boot rom. an advanced power management unit (pmu) is incorporated in ch7515, which is specially designed to reduce power consumption in normal operation.

结构图

数据表

应用说明

pcb layout and design guide for ch7515 an-b021 rev1.0

技术报告

暂无信息

规格

input interface edp/dp

output interface lvds

audio interface iis, spdif output

other features  no

package type lqfp128

订单信息

part number package type operating temperature range minimum order quantity

ch7515a-tf  128 tqfp, lead-freecommercial : -20 to 70°c90/tray
